Research and Prototype Foundry

Enabling excellence in micro- and nano-fabrication

The Research and Prototype Foundry offers instruments and expertise for researchers to transform their ideas for devices and structures at the micro- and nano-scale into reality by providing them access to fabrication expertise, processes, and equipment.

The Research and Prototype Foundry is based at the Sydney Nanoscience Hub and is a member of the Australian National Fabrication Facility network. The facility provides access to state-of-the-art instruments for the fabrication of devices and structures with features on the micro and nanoscale. As well as specialised processes allowing users to make devices and prototype new ideas. 

Our aim is to provide access to well supported, state-of-the-art tools for micro- and nano-fabrication, backed up by a team of expert process engineers. We enable the development of a wide range of research material and devices, including optical chips, electronic devices and new quantum science and technology via outstanding lithography, etching, deposition, and metrology capabilities.

Capabilities

Deposition

Vacuum deposition is a family of processes used to deposit layers of material atom-by-atom or molecule-by-molecule on the surface of a substrate. The deposited layers can range from a few atomic layers to several micrometres. The films are made in a highly controlled environment and multiple materials can be combined through mixing, layering, or other means to tune the behaviour of the material. Based on the vapor source, vacuum deposition can be divided into two broad categories: physical vapor deposition (PVD) and chemical vapor deposition (CVD).

Tools:  Atomic Layer Deposition Picosun R200
            E-Beam/Thermal Evaporator AJA ATC-1800-E
            Sputter Coater DC Emitech K550
            Sputterer AJA ATC-2000-UHV
            Lamp Annealer ULVAC MILA 5000

Etching

Micro-to-nano fabrication dry etching technology provides engineers and scientists ways to remove materials with atomic precision. With proper chemistry, reactive ion etching (RIE) removes one material rapidly while slowly etching another. This contrast enables a pattern from a thin stencil to be transferred deep into a material, providing a desirable aspect ratio. On the other hand, a heavy gas such as argon can be blasted at the material to erode its surface, leading to a more milling effect.

Tools:  ICP RIE Oxford Plasmalab 100
            O2 Plasma Asher Glow
            Reactive Ion Etcher (Plasmatherm Vision)
            Reactive Ion Etcher (South Bay RIE3000)
            Wet Benches

Fibre Bragg Grating

The Advance Fibre Bragg Grating (FBG) facility is a new inclusion to RPF facility. The FBG facility is based on technology developed and engineered for more than 20 years. The FBG facility can fabricate complicated FBG designs of arbitrary amplitude and phase with high fidelity and quality. FBGs are useful optical components for sensing, optical communications, and optical signal processing.

A FBG is constructed with index modulation fabricated on a section of fibre by UV laser exposure. A typical application is for optical filters used in optical undersea cables which accounts for 99% of data traffic that is crossing oceans. Photonic components, modules and subsystems made by FBGs, such as fibre lasers, are also widely used.

Tools:  FBG writing rig
            FBG test station – LUNA OVA Optical Vector Analyzer,             Agilent Tunable Laser
            FBG annealing station
            Fibre laser test station

Fibre Fabrication

Fibre fabrication is a process for making long uniform lengths of fibre, typically of dimensions between tens of microns and millimetres, and typically with complex transverse structure. This structure can provide waveguiding, or engineering mechanical, electrical, magnetic, or fluidic functionalities. It is typically a two stage process where the desired structure is assembled on macroscale, in a “preform”, and this is then drawn in a furnace down to fibre. Glasses and thermoplastics are readily drawn and can be co-drawn with some metals. The preforms may be produced by a variety of techniques including “stacking and drawing”, milling, or casting, and the fibre is drawn on a draw tower.

Our fibre manufacturing capabilities include polymers, soft glass, waveguides, co-drawn wires, and air or fluidic microstructures. Our manufacturing equipment includes a six-meter dual sided Heathway fibre draw tower for primary and secondary drawing with three furnace options for various preform sizes and temperature requirements. A pressurised fibre coating system, tractor draw unit for capillary / cane drawing, a pressurised drawing system, and spinning motor chuck mount for drawing spun fibres.

We run a CNC mill on site which allows us to accurately drill holes in various materials, giving us the ability to draw those materials down into fibres whilst maintaining the hole structures using internal pressure.

Tools:  Fibre Draw Tower
            CNC Mill

Lithography

Direct laser lithography is a process used to directly transfer a design pattern into a photo sensitive polymer coated onto a substrate such as glass or silicon. The focused laser light (generally 370 or 405nm) is used to modify the polymer to make the material more soluble during development or to cross link the polymer causing it to remain during development. The advantage of this approach is that it negates the use of expensive chrome masks and speeds up the development cycle of devices. It also overcomes some of the other technical shortcomings of contact lithography such as resolution and process uniformity.

We have a suite of tools for optical lithography, as well as substantial supporting tools for spin coating and developing. The DWL66+ and MLA100 are direct write photolithography tools, allowing the exposure process to be done without the use of a photomask.

Electron Beam Lithography (EBL) allows users to write patterns with extremely high resolution, smaller than 10nm in size. Due to the high-resolution nature of the technique, EBL has a vast range of applications including nano-electronics, photonics, plasmonics, nano-fluidics, MEMS, x-ray, and neutron optics.

Tools:  Dry Film Laminator Fortex FL-0305-01
            EBL Elionix ELS-F125
            i-line Stepper ASML PAS 5500/100
            Laser Writer Heidelberg DWL 66+
            Mask Aligner EVG 610
            Maskless Aligner Heidelberg MLA100
            Spin Dryer Delta 15
            Wafer Track Processor Rite Track SVG88

Metrology

Metrology is a critical part of the fabrication process, allowing verification of design, processes, and functionality. The RPF’s current capability includes two high-end scanning beam systems, Nanofab Helium Ion Beam and FIB-SEM, from Zeiss, as well as Bruker Atomic Force Microscope, DekTak Stylus Profilometer, a Leica DCM8 3D microscope, a Reflectometer, an Ellipsometer, a number of optical microscopes, and electrical testing probe stations.

Scanning Electron Microscopy (SEM) is the process whereby a tightly focused electron beam is scanned onto the surface to be imaged. SEM is a key tool for process characterisation of surface topography, cross-section profiles, elemental composition, and crystallography. Atomic force microscopy (AFM) is a versatile technology consisting of many characterisation methods. AFM performs scanning probe microscopy, scanning the surface of a material with a nanoscale cantilever, either through direct contact or through oscillating the cantilever just above the surface. AFM has a wide range of applications including nanoscale materials and surface characterisation, electrical materials characterisation, interaction forces and mechanical properties mapping. The Reflectometer and Ellipsometer offer characterisation of thin films, while optical microscopy uses a series of lenses to focus light that is reflected from or passed through a sample; various forms of light and magnification can be used to visualise the sample. Probe stations characterise electrical properties and device functionality.

Tools:  3D Microscope Leica DCM8
            Atomic Force Microscope Bruker Icon
            Ellipsometer JA Woollam M2000
            FIB-SEM Zeiss Crossbeam 550XL
            Microscope Nikon Eclipse LV100ND
            Digital Microscope Olympus DSX510
            NanoFab Helium Ion Beam Zeiss
            Stylus Profilometer DekTak XT

Packaging

Device packaging is the final step in the fabrication process. Packaging of a micro- or nano-electrical device allows components to be operated in applied environments by providing mechanical stability and functionality. Wire bonding allows nanoscale electrical components to communicate with the outside world, with thin electrically conductive wires allowing electricity to flow from contacts on the component to, or from, its packaging. Bonding a wafer to another wafer can help a form new functions in a device or can ensure mechanical and hermetic encapsulation of devices and electronics. Other packaging tools include dicing saws, used to separate nanofabricated devices, and probe stations, used to electrically probe nanoscale electrical components prior to mechanical and electrical packaging.

Tools:  Dicing Saw ADT 7122
            Die Bonder Finetech Lambda
            Probe Station Suss PM 5
            Wire Bonder TPT HB100

Photomask fabrication service

The RPF provides full service for chrome-glass photomask fabrication with client's design and requirements. Photolithography is used to create a pattern on a substrate by shining light from a light source onto a photoresist that coats the surface of the substrate through a photomask and is followed by a development phase. Depending on the complexity of a device’s design, various deposition, etching, and lithography processes can be cycled through many times. Each mask used must be aligned perfectly to the previously processed layer if the final device is to operate as desired.

Prototyping

Prototyping is a quick way to produce unique parts, or for small production runs, and is useful when wanting to rapidly create prototypes with small variations in design. Prototyping capabilities include equipment which take a computer aided design model to generate components, such as laser cutters and 3D printers. 3D printing involves taking a model and slicing into layers, then printing these layers on top of one another to recreate a 3D component.

Tools:  3D printer - Resin Formlabs 3B
            3D printer - Filament Funlab HT
            3D printer - Flexible Filament Creator Pro
            Laser cutter Universal VLS3.60

Soft Lithography

Soft lithography is a technique used to imprint structures into mechanically soft materials from a master mould or stamp. This method of pattern transfer is used to make microfluidic devices for applications which require biocompatible materials such as Polydimethylsiloxane (PDMS). Equipment includes spin coaters (for thin layers), ovens, mixers, and casting equipment

Tools:  Coater Brewer Science CB-200
            PDMS Process Tools

Wet Processing

The fabrication of micro and nanoscale devices requires the use of many wet chemical processes. Wet processing encompasses the processing of chemicals to clean, deposit material onto, and etch material away from substrates and components. Wet benches allow users to access solvent, caustic, and acid-based processing in a safe and dedicated environment.

Tools: Wet Benches  (Acid, Caustic, Chromium, HF, Solvent)

Facilities & Access

Cleanroom Level 2 Sydney Nanoscience Hub (A31)
Approximately 700sqm of ISO 5 cleanroom space which houses Sydney’s deposition, etching, lithography, metrology, and wet processing facilities.
Packaging & Soft Lithography Facility                         Lab 3021 Sydney Nanoscience Hub (A31)
Approximately 75sqm of semi-clean space for PDMS processing and packaging.
Fibre Fabrication Facility Physics Building (A28)
Fibre draw tower and CNC mill.
Advanced Fibre Bragg Grating Facility Physics Building (A28)
FBG writing, testing, and annealing, plus fibre laser testing
Prototyping Facility Lab 224A Madsen Building (F09)
3D printers and laser cutter.
Send us your project goals and requirements, and our staff will put together a tailored registration and training program to ensure that you can make the most of our facilities.

  1. Consultation. Once we receive your project enquiry, our staff will work with you to put together a viable project design, taking into account factors such as experimental scope, instrument requirements, and budget.
  2. Activation. We will assist you in registering your project, and will guide you through any necessary formalities prior to project commencement.
  3. Induction. We will organise a bespoke instrument training program specific to your needs, giving you autonomous access to our facilities to complete your project.
